Metric Step Drill

$13.00

All the drills you need for FTC in one handy tool!

20 in stock (can be backordered)

Description

Specifications

  • Maximum material thickness: 3mm
  • Tool material: High-Speed Steel
  • Shank: 0.25in Hex
  • 10 unique diameters
    • 3, 4, 5, 6, 7, 8, 9, 10, 11, & 12 mm

Hole Size Compatibility

  • 3mm
    • Clearance for M3 screws
    • REV screw standard
  • 4mm
    • Clearance for Matrix M4 screw and 4mm axle standard
  • 6mm
    • Clearance for Tetrix and AndyMark 6mm D-shaft
  • 8mm
    • Tetrix Bushing size
  • 9mm
    • REV Plastic Bearing size
    • REV Motion Bracket hole size
  • 10mm
    • 106-2Z 6x10x3mm standard ball bearing size
  • 12mm
    • REV HD Hex Motor pilot hole
    • AndyMark NeveRest Motor pilot hole
    • 126-2Z 6x12x4mm standard ball bearing size
